Toyota Tundra Towing Capacity Guide

Toyota Tundra Towing Capacity Guide at Germain Toyota of Columbus
Whether you need the extra muscle to tackle the toughest jobs in your industry or you intend to make long-lasting memories with your loved ones, having a truck capable of towing your most prized possessions is an important quality for many pickup truck shoppers. Fortunately, towing and hauling are two key strengths of the proven Toyota Tundra. If you’ve been wondering exactly how much the Tundra can tow or what towing-related features are available on this full-size truck – you’ve come to the right place! Our team at Germain Toyota of Columbus has created this informative Toyota Tundra towing capacity guide. Let’s begin!
View New Tundra Inventory
View Tundra Model Overview

How Much Can the Tundra Tow?

Toyota Tundra Towing

i-FORCE 3.4L Twin-Turbo V6 4×2

Double Cab 6.5-foot Standard Bed Double Cab 8.1-foot Long Bed CrewMax 5.5-foot Short Bed CrewMax 6.5-foot Standard Bed
SR 8,300 lbs 8,300 lbs 8,300 lbs •
SR5 12,000 lbs 11,370 lbs 11,400 lbs 11,270 lbs
Limited 11,400 lbs • 11,350 lbs 11,230 lbs
Platinum • • 11,310 lbs 11,180 lbs
1794 Edition • • 11,380 lbs 11,290 lbs

Scroll Right to View Information

i-FORCE 3.4L Twin-Turbo V6 4×4

Double Cab 6.5-foot Standard Bed Double Cab 8.1-foot Long Bed CrewMax 5.5-foot Short Bed CrewMax 6.5-foot Standard Bed
SR 8,300 lbs 8,300 lbs 8,300 lbs •
SR5 11,200 lbs 11,090 lbs 11,160 lbs 11,010 lbs
Limited 11,110 lbs • 11,120 lbs 10,970 lbs
Platinum • • 11,050 lbs 10,890 lb
1794 Edition • • 11,050 lbs 10,890 lbs

Scroll Right to View Information

i-FORCE MAX 3.4L Twin-Turbo Hybrid V6 4×2

Double Cab 6.5-foot Standard Bed Double Cab 8.1-foot Long Bed CrewMax 5.5-foot Short Bed CrewMax 6.5-foot Standard Bed
Limited • • 11,450 lbs 11,350 lbs
Platinum • • 11,380 lbs 11,290 lbs
1794 Edition • • 11,380 lbs 11,290 lbs

Scroll Right to View Information

i-FORCE 3.4L Twin-Turbo V6 4×4

Double Cab 6.5-foot Standard Bed Double Cab 8.1-foot Long Bed CrewMax 5.5-foot Short Bed CrewMax 6.5-foot Standard Bed
SR • • 11,170 lbs 11,040 lbs
SR5 • • 11,020 lbs 10,960 lbs
Limited • • 11,020 lbs 10,960 lbs
Platinum • • 11,175 lbs •
1794 Edition • • 10,340 lbs •

Scroll Right to View Information

With two available engine choices, the Toyota Tundra offers plenty of capability to individuals searching for the ultimate tow vehicle. The standard i-FORCE 3.4L Twin-Turbo V6, offered in both 4X2 and 4X4 drivetrain configurations, offers the highest towing ratings. In fact, choosing the Tundra SR5 Double Cab with the 6.5-foot standard bed option means that you’ll enjoy a maximum towing capacity of up to 12,000 pounds. The majority of trim levels slotted above the base-tier SR deliver close to this maximum figure as well. Shoppers can also step up to the available i-FORCE MAX 3.4L Twin-Turbo V6 Hybrid powertrain to experience a blend of efficiency and muscle to help tow. 11,450 pounds is the highest maximum towing capacity of this upgraded engine.
Toyota Tundra Towing Features

Toyota Tundra Towing Features

Helping you lead the pack, the Toyota Tundra is also available with plenty of innovative towing-related features that help you work both harder and smarter.

Tow Mirrors

Power-extendable and power-folding, these optional mirrors provide a clearer view of your surroundings for enhanced confidence behind the wheel.

Class-IV Towing Hitch Receiver

Standard on most Tundra models, you’ll also receive a wiring harness with a 7-pin/4-pin connector to seamlessly connect to your trailer.

Integrated Trailer Brake Controller (ITBC) with Multi-Information Display (MID)

This handy screen lets you view key information including trailer brake type, gain, and manual trailer brake output controls.

Trailer Backup Guide System with Straight Path Assist (SPA)

A clever feature available on select Tundra models, it’s now easier than ever before to get hitched up to your trailer.

Trailer-Sway Control (TSC)

Helping you keep things under control, this safety feature helps mitigate and eliminate trailer sway by providing helpful assistance.

View New Tundra Inventory
View Tundra Model Overview

*Never tow beyond a vehicle’s published towing capacities. Before towing, confirm your vehicle and trailer are compatible, hooked up and loaded properly and that you have any necessary additional equipment. The maximum you can tow depends on base curb weight plus the total weight of any cargo, occupants, and added vehicle equipment. Follow all instructions in your Owner’s Manual.
